3/8" Pitch New Technology Excellent Cutter Saw Chain For Chain Saw Heavy Duty Conveyor Chains
Features: high strength, wear resistance, high surface hardness.
Operating requirements: well lubricated and a suitable cutting machine should be fixed.
Uses: Saw chains are mainly used in wood cutting and wood industry.
Quick Details
| Engine Displacement | 30CC |
| Power | 1400W |
| Place of Origin | Zhejiang, China |
| Brand Name | UCER |
| Model Number | .325"chainsaw saw chain |
| Feature | 2-Stroke, 4-Stroke, Anti-slip, Folding Handle, Forced Air Cooling, Height Adjustable Handles, Single Cylinder, Telescopic Handle, Other |
| Certification | ISO9001 |
| Power Type | Petrol / Gas |
| Saw chain pitch | 3/8" |
| Material of saw chains | SAE 8660 |
| OEM service | Available |
| Saw chain color | Nature ,blue |
| Saw chain weight | 0.28kg/pc of 76links .325"saw chain |
| Last life | 13hours continuously use |
| Saw chain's HS code | 8202400000 |
| Common length | 76 Links |
| Cutter Type | Semi-chisel (Full chisel) |
| Saw chain package | Reels or loops |
Specification
3/8" pitch new technology excellent cutter saw chain for chain saw
This saw chain are all produced by our all company,with excellent cutter.Our brand is "Gelin"
Manufactured to exacting standards of quality, strength and durability.
Engineered for precision, balance and low vibration
All chains are manufactured with advanced heat treatment and hard chrome to allow for improved cutter performance.
| Pitch | Gauge | Item NO. | File Size | Sharpening Angle | File Position | Depth Gauge |
| 1/4'' | .050''/1.3mm | E1,E1T | 5/32'' 4.0mm | 30° | 10° | .025''/.65mm |
| 3/8''LP | .043''/1.1mm | A0,A0FT | 11/64'' 4.5mm | 30° | 0° | .025''/.65mm |
| .050/1.3mm | A1,A1FT | 5/32'' 4.0mm | 30° | 0° | .025''/.65mm |
| .325'' | .050''/1.3mm .058''/1.5mm .063''/1.6mm | B1,B2,B3,B1FT | 3/16'' 4.8mm | 30° | 10° | .022''/.55mm |
| B2S,B3S,B2SFT | 3/16'' 4.8mm | 28° | 10° | .022''/.55mm |
| 3/8'' | .050''/1.3mm .058''/1.5mm .063''/1.6mm | C1,C2,C3,C2FT,C3FT | 7/32'' 5.5mm | 30° | 10° | .022''/.55mm |
| C1S,C2S,C2SFT,C3SFT | 7/32'' 5.5mm | 28° | 10° | .022''/.55mm |
| .404'' | .063''/1.6mm | D3A,D3R | 7/32'' 5.5mm | 30° | 10° | .030''/75mm |
| .080''/2.0mm | D4 | 7/32'' 5.5mm | 30° | 10° | .050''/1.2mm |
Packing Delivery Shipping
Packaging Details:
Packing: plastic bag+carton+plywood case
Port: shanghai ,ningbo
